Alpine Pure powered 18 US Gal Per Minute UV with two 20 inch Big Grey Heavy Duty NSF Approved housings. One inch ports for a full flow of up to 80 LPM. Fully assembled with 304 New Zealand Made Stainless Steel brackets and water proof cover so this unit can be installed out in the rain. 40 Watt High Output lamp for large water flow and low energy costs. Genuine Alpine Pure Gradient Density, Polyspun NSF Approved 20 micron and 1 micron prefilters installed as standard.
This UV system is Watermarked and perfectly suited for a 2-4 bathroom home.
This was the UV system the boss chose for his bach, so if high peak flows and safe water is your primary objective this is your safe choice.
Pressure gauges are included with the covered option.
We assemble this system as standard with a right hand side water entry, but we can assemble it with water entering from the left hand side if requested using the option below.
This UV system is Watermarked and perfectly suited for a 2-4 bathroom home.
This was the UV system the boss chose for his bach, so if high peak flows and safe water is your primary objective this is your safe choice.
Pressure gauges are included with the covered option.
We assemble this system as standard with a right hand side water entry, but we can assemble it with water entering from the left hand side if requested using the option below.
RRP Priced from:
NZ$ 1,940.00
Price Priced from:
NZ$ 1,559.00 including GST
BUG GLD
| Applications | whole house (medium to large) |
| Height | 750 mm |
| Width | 600 mm |
| Depth | 220 mm |
| Max. Flow Rate (UV dose >16,000 µWs/cm2)* |
36 GPM (136 LPM) |
| Max. Flow Rate (UV dose >30,000 µWs/cm2)* |
18 GPM (68 LPM) |
| Max. Flow Rate (UV dose >40,000 µWs/cm2)* |
13.5 GPM (51 LPM) |
| Water Chamber Material | 304 Stainless Steel |
| Chamber Length | 18.6 inches / 472 mm |
| Chamber Diameter | 3.5 inches / 89 mm |
| Controller Size | 7.13 x 3.75 x 1.96 inches (181 x 95 x 50 mm) |
| Controller | AP BAL 100 |
| Lamp | AP LP 422 |
| Sleeve | AP QS 452 |
| Electrical | 100-240v, 50/60HZ |
| Power Consumption | 40 watts |
| Lamp Power | 40 watts High Output |
| Inlet / Outlet Plumbing Ports | 1" |
| "Power-On" Indicator Light | YES |
| Audible Lamp Failure Alarm | YES |
| Lamp Replacement Reminder | YES |
